Wednesday, March 30, 2011
Car99r's TCU Build Off Bike
You may remember the post from back in January about Chris Robertson's Build-off Bike for the TCU forum. If not, scoll to the bottom of the page or look thru the "past posts" on the sidebar.
Anyway, here is the Honda Shadow VLX 600 as it sits today, ready for the street. More proof that with with a cheap donor and a little imagination you can have a cool looking scoot without spending an arm and a leg to do so.
Anyway, here is the Honda Shadow VLX 600 as it sits today, ready for the street. More proof that with with a cheap donor and a little imagination you can have a cool looking scoot without spending an arm and a leg to do so.
Friday, March 25, 2011
Repairing the "konged" Honda CB750
Last sunday the SG crew came over and we did some repair work on my '74 CB750 bobber.
Over the past decade of abusing her across 14 states and thousands of miles, the rails behind the seat area had bent forward. CB750 tubing is quite thin walled and the area wasn't gusseted initially, mainly because of how the seat fits on. I guess it could only take so much pounding from the rear before it finally just had to give.
We started by firing the torch and bending the rails back to their straight and level postion. When I initially noticed that the rails were bent, I had suspected there were cracks. Once heated and bent back, the areas around the welds opened right up. This led me to believe the frame had actually been cracked as I had thought.
Once we determined that simply bending them back into position was a pipe dream, we opted for what I had planned on doing from the beginning, cut and replace. We made sure the bike was sitting level and measured up from the lower engine mount area 7.5" to where we would cut off the bent rails. After double checking our measurements a few times and marking them with tape, we cut em off.
Next we cut two 4.5" pieces of tubing that had a slightly smaller o.d. than the i.d. of the frame's tubing for sleeves. This would allow 2.25" on each side of the seam. We then measued up the same distance on a donor stock rear end (Thanks Dock!!! http://vintagepureheaven.blogspot.com/) and cut them in the same place we cut off the junk ones. We then had our two new replacement pieces for the seat/fender rails.
After cleaning up the metal and drilling holes for plug welds we thought we'd see how it all fit together. The left side slid right on and with a few light raps from a rubber mallet seated itself nicely. The right side was a bit more stubborn as there was a slight burr about 1/2" from our cut inside the frames tubing. After realizing that trying to file it down wasn't gonna work out, we opted for sliding the rail down on the sleeve as far as it would go and applying some heat to it while tapping it with a BFH until that burr was soft enough that it slid down to where it needed to seat.
We checked the levelness periodically thru this process. We also checked for centeredness before final welds. Once we had it all in place it was tacked and welded.
I mentioned above the lack of room for gussets. Even though the tubing was now twice as thick in the problem area, it would still be susceptible to stress because of shock angle and where its located on the frame. We put the fender and seat on to determine how much space we actually did have to work with. We figured if we angled the gussets that we could squeeze them in between the fender and the bottom of the seat pan.
Some cardboard patterns were then sketched and then gussets were cut from 3/8" steel...nice and beefy. Where the gussets are located will be completely hidden from sight once the fender and seat are reinstalled. The extra metal that you see in some of these pics was also hacked off, the old fender brace/mount and the left over portion of the stock seat rails.
I still have to clean up the metal a bit and get some paint on 'er. I'm also going to do tend to some other issues and things I've been meaning to get to. With her this far torn down, its time to stop the abuse and apply a little TLC.
Over the past decade of abusing her across 14 states and thousands of miles, the rails behind the seat area had bent forward. CB750 tubing is quite thin walled and the area wasn't gusseted initially, mainly because of how the seat fits on. I guess it could only take so much pounding from the rear before it finally just had to give.
We started by firing the torch and bending the rails back to their straight and level postion. When I initially noticed that the rails were bent, I had suspected there were cracks. Once heated and bent back, the areas around the welds opened right up. This led me to believe the frame had actually been cracked as I had thought.
Once we determined that simply bending them back into position was a pipe dream, we opted for what I had planned on doing from the beginning, cut and replace. We made sure the bike was sitting level and measured up from the lower engine mount area 7.5" to where we would cut off the bent rails. After double checking our measurements a few times and marking them with tape, we cut em off.
Next we cut two 4.5" pieces of tubing that had a slightly smaller o.d. than the i.d. of the frame's tubing for sleeves. This would allow 2.25" on each side of the seam. We then measued up the same distance on a donor stock rear end (Thanks Dock!!! http://vintagepureheaven.blogspot.com/) and cut them in the same place we cut off the junk ones. We then had our two new replacement pieces for the seat/fender rails.
After cleaning up the metal and drilling holes for plug welds we thought we'd see how it all fit together. The left side slid right on and with a few light raps from a rubber mallet seated itself nicely. The right side was a bit more stubborn as there was a slight burr about 1/2" from our cut inside the frames tubing. After realizing that trying to file it down wasn't gonna work out, we opted for sliding the rail down on the sleeve as far as it would go and applying some heat to it while tapping it with a BFH until that burr was soft enough that it slid down to where it needed to seat.
We checked the levelness periodically thru this process. We also checked for centeredness before final welds. Once we had it all in place it was tacked and welded.
I mentioned above the lack of room for gussets. Even though the tubing was now twice as thick in the problem area, it would still be susceptible to stress because of shock angle and where its located on the frame. We put the fender and seat on to determine how much space we actually did have to work with. We figured if we angled the gussets that we could squeeze them in between the fender and the bottom of the seat pan.
Some cardboard patterns were then sketched and then gussets were cut from 3/8" steel...nice and beefy. Where the gussets are located will be completely hidden from sight once the fender and seat are reinstalled. The extra metal that you see in some of these pics was also hacked off, the old fender brace/mount and the left over portion of the stock seat rails.
I still have to clean up the metal a bit and get some paint on 'er. I'm also going to do tend to some other issues and things I've been meaning to get to. With her this far torn down, its time to stop the abuse and apply a little TLC.
Wednesday, March 23, 2011
Wednesday, March 16, 2011
Tuesday, March 15, 2011
Always waiting...
Well we should have the sticker orders back soon, within the next few weeks for sure. The classic logo sticker and a new design also. Shirts are at the printers also, not sure of when they'll be in though...I'll post when I find out.
I'm waiting on this rain to stop and the weather to get nice too!
One thing I'm not waiting on is parts...for a change, haha.
Been holed up in the garage lately though, so thats good for the soul!
Waiting for sunday when I plan to do some fandanglin' and attempt to unbend the frame on my CB750 bobber.
The rear rails have bent upward/forward at the seat area...after a decade though, so she had a pretty good run all in all. Gonna gusset that sucker this time!
Worse case, I have to hack the rear section entirely off and graft the new one on that I picked up from my buddy Dock (Mt. Airy Cyclery, NC).
So I figured its worth a try to heat and bend it back...if its cracked or kinked, well then, on to plan B.
Right now though, I'm just waiting for 4 o'clock.
I'm waiting on this rain to stop and the weather to get nice too!
One thing I'm not waiting on is parts...for a change, haha.
Been holed up in the garage lately though, so thats good for the soul!
Waiting for sunday when I plan to do some fandanglin' and attempt to unbend the frame on my CB750 bobber.
The rear rails have bent upward/forward at the seat area...after a decade though, so she had a pretty good run all in all. Gonna gusset that sucker this time!
Worse case, I have to hack the rear section entirely off and graft the new one on that I picked up from my buddy Dock (Mt. Airy Cyclery, NC).
So I figured its worth a try to heat and bend it back...if its cracked or kinked, well then, on to plan B.
Right now though, I'm just waiting for 4 o'clock.
Monday, March 7, 2011
Rest in Peace KONG
It was this month back in 2008 when I got a phone call.
The number on my cell phone came up Rick "Kong" Wilkey.
I was at Sunday dinner with family so I skipped the call, figured I'd call him back once home and in the garage.
After returning home, I exliled myself to the shop to get some stuff done.
Before I could return the earlier call, I heard the phone ring again.
My girlfriend answered it, "hey Rick!"
It wasn't Rick.
It was his wife.
She said Rick had died "yesterday".
I was in shock.
On Saturday Feb 26, 2011, while I was out and about I pulled into the graveyard to visit my buddy.
Seeing the wind had scattered some flowers and a toy motorcycle that adorned his grave, I picked up a bit and rearranged the items back to their original place.
Later that night I went to see some buddy's bands at a local watering hole we used to stop in at while out riding. There I ran into his daughter who I hadn't seen since the funeral.
This date sorta crept up on me and I just thought it was a bit odd that those few things all happened in such close proximity of the annivesary of his passing. I wasn't even thinking about it being close to March when I pulled into the graveyard, it was just a whim. I also didn't expect to see his daughter later that night. Next thing I know a few days later was the day he passed.
As my girlfriend stated when I told her about all this...."he was around".
RIP buddy, you are missed.
The number on my cell phone came up Rick "Kong" Wilkey.
I was at Sunday dinner with family so I skipped the call, figured I'd call him back once home and in the garage.
After returning home, I exliled myself to the shop to get some stuff done.
Before I could return the earlier call, I heard the phone ring again.
My girlfriend answered it, "hey Rick!"
It wasn't Rick.
It was his wife.
She said Rick had died "yesterday".
I was in shock.
On Saturday Feb 26, 2011, while I was out and about I pulled into the graveyard to visit my buddy.
Seeing the wind had scattered some flowers and a toy motorcycle that adorned his grave, I picked up a bit and rearranged the items back to their original place.
Later that night I went to see some buddy's bands at a local watering hole we used to stop in at while out riding. There I ran into his daughter who I hadn't seen since the funeral.
This date sorta crept up on me and I just thought it was a bit odd that those few things all happened in such close proximity of the annivesary of his passing. I wasn't even thinking about it being close to March when I pulled into the graveyard, it was just a whim. I also didn't expect to see his daughter later that night. Next thing I know a few days later was the day he passed.
As my girlfriend stated when I told her about all this...."he was around".
RIP buddy, you are missed.
Friday, March 4, 2011
Thursday, March 3, 2011
